One for oneHigh-speed flat mask production line


Product features:
1. The machine runs at high speed and has stable performance.
2. Using ultrasonic welding technology, the finished product is beautiful, hygienic and environmentally friendly.
3. The entire production line is automated from feeding, nose line insertion, edge banding, and cutting of finished products.
Efficient and labor saving.
4. The frame structure is made of aluminum alloy, and the key parts are made of stainless steel. The whole line has the characteristics of no rust, durability, easy cleaning, and beautiful appearance.
5. Computer PLC programming control, servo drive, high degree of automation. High stability, low failure rate and low noise.

Dimensions:

Main configuration table:

No. Name Brand Quantity
1 HMI Schneider 1
2 PLC Schneider 1
3 M241 controller Schneider 2
4 servo motor Schneider 8
5 server Driver Schneider 8
6 Intermediate relay Omoron 2
7 photoelectric sensor Omoron 10
8 Circuit breaker Schneider 1
9 Contactor Schneider 1
10 Switching power supply Schneider 2
11 Switch Schneider 2
12 Emergency stop switch Schneider 2
13 2-position switch Schneider 2
14

Pneumatic components

SMC All solenoid valves and cylinders


Technical parameters:
1. Land size: 4336*3268*1985MM(L*W*H)
2. Weight: 1500KG
3. The maximum working pressure of the system: 0.7Mpa
4. System rated working pressure: 0.5~0.7Mpa
5. Input voltage: 220V AC
6. Power: 10KW
7. Dry humidity: 20~80%RH (no condensation)
8. Ambient temperature: 5~40°C
9. Speed: 80-120 pieces/min
