HFB-35Automatic strapping machine
Overview:
HFB-35 automatic packing machine is a new product developed by our company by absorbing foreign technology and combining with foreign technology. It fills the gap of packing after packing in pharmaceutical enterprises, and can be linked to unpacking and packing, realizing a complete packing production line. The body and components of the equipment are all aluminum high-end advanced design, imported imported electrical components, PLC, man-machine interface operation, make the equipment operation process more stable and convenient, can be used in the pharmaceutical, food, cosmetics industries, the equipment complies with CGMP standards .
Main technical parameters:
| Type Number | HFB-35 automatic strapping machine |
| Bale size (LxWxH) |
The maximum is 250*250*300(MM) The minimum is 50*60*90(MM) (this size is the package size) |
| Use packaging |
PE film Applicable cable tie specifications (width): 30~80mm Binding film thickness: 30~80um |
| strapping speed | The strapping speed is 25~35 pieces per minute |
| Working power | 220V/50Hz |
| equipment power | 3000W |
| working pressure | The working air pressure is not less than 0.6 MPa, and the exhaust volume: 0.3 cubic meters per minute |
| Dimensions | 2800x1000x1750mm (plus conveyor belt size) |
| total weight of equipment | 890kg |
